Based on domestic globalization, with a broad vision
Construction site specific vehicles;
More powerful power, choose from lead-acid lithium battery models at will;
More passability under complex working conditions;
Standard waterproof handle head;
New drive system, fully sealed gearbox;
Metal casing has a longer lifespan;
Stable and reliable;
Construction site specific vehicles;
More powerful power, choose from lead-acid lithium battery models at will;
More passability under complex working conditions;
Standard waterproof handle head;
New drive system, fully sealed gearbox;
Metal casing has a longer lifespan;
Stable and reliable;
| 1.1 | brand | Zhongli | Zhongli | |
| 1.2 | model | EPT20-20ETH (Hanjingang) construction site lithium battery model | EPT20-20ETH (Hanjingang) construction site lead-acid model | |
| 1.3 | Power type | electric | electric | |
| 1.4 | Operation Type | Walking | Walking | |
| 1.5 | Load Rated | Q (kg) | 2000 | 2000 |
| 1.6 | Load center distance | c (mm) | 600 | 600 |
| 2.1 | Self-weight (including battery) | kg | 200 | 230 |
| 3.2 | Front wheel size (diameter × width) | F210x70 | F210x70 |
| 4.4. | Standard maximum lifting height | h3 (mm) | 115 | 115 |
| 4.15 | The height of the fork after it drops | h13(mm) | 105 | 105 |
| 4.19 | The length of the whole vehicle | l1 (mm) | 1673 | 1673 |
| 4.21 | Overall width | b1/ b2 (mm) | 685 | 685 |
| 4.34.1 | Right angle stacking channel width (pallet is 1000 length × 1200 width) | Ast (mm) | 2307 | 2307 |
| 4.34.2 | Right angle stacking channel width (pallet is 800 width x 1200 length) | Ast (mm) | 2179 | 2179 |
| 4.35 | Turning radius | Wa (mm) | 1505 | 1505 |
| 5.1 | Walking speed, full load/no load | km/ h | 4/4.5 | 4/4.5 |
| 5.8 | Maximum climbing, full/unloaded | % | 8/20 | 8/20 |
| 6.4 | Battery voltage/nominal capacity | V/ ah | 48/20 | 48/40 |
