Technical Parameter
feature
| 1.1 |
brand |
|
Zhongli |
| 1.2 |
model |
|
DS2 |
| 1.3 |
Power type |
|
electric |
| 1.4 |
Operation Type |
|
Walking |
| 1.5 |
Load Rated |
Q (kg) |
1500 |
| 1.6 |
Load center distance |
c (mm) |
500 |
weight
| 2.1 |
Self-weight (including battery) |
kg |
485 |
size
| 4.2 |
The lowest height of the gantry after the drop |
H1 (mm) |
1817 |
| 4.4 |
Standard maximum lifting height of gantry |
h3 (mm) |
2430 |
| 4.15 |
The height of the fork after it drops |
h13(mm) |
90 |
| 4.19 |
The length of the whole vehicle |
l1 (mm) |
1713 |
| 4.21 |
Overall width |
b1/ b2 (mm) |
890 |
| 4.25 |
Forks with width |
b5 (mm) |
570 |
| 4.34.1 |
Right angle stacking channel width (pallet is 1000 length × 1200 width) |
Ast (mm) |
2300 |
| 4.34.2 |
Right angle stacking channel width (pallet is 800 width x 1200 length) |
Ast (mm) |
2232 |
| 4.35 |
Turning radius |
Wa (mm) |
1468 |
Performance parameters
| 5.1 |
Walking speed, full load/no load |
km/ h |
3.7/4.0 |
| 5.2 |
Lift speed, full load/no load |
m/ s |
0.085/0.13 |
Electric motor, power unit
| 6.4 |
Battery voltage/nominal capacity |
V/ ah |
24/80 |
