Based on domestic globalization, with a broad vision
High level stacking without tipping over, with good stability;
Explosion proof design of hydraulic system, safer;
Equipped with a long handle for easier operation;
Stylish appearance and good overall strength;
Easy disassembly and assembly of the body, more worry free maintenance;
High level stacking without tipping over, with good stability;
Explosion proof design of hydraulic system, safer;
Equipped with a long handle for easier operation;
Stylish appearance and good overall strength;
Easy disassembly and assembly of the body, more worry free maintenance;
| 1.1 | brand | Zhongli | |
| 1.2 | model | DS3 | |
| 1.3 | Power type | electric | |
| 1.4 | Operation Type | Walking | |
| 1.5 | Load Rated | Q (kg) | 1500 |
| 1.6 | Load center distance | c (mm) | 500 |
| 2.1 | Self-weight (including battery) | kg | 510 |
| 3.1 | Tire type, drive wheel/load wheel (steering wheel) | Polyurethane |
| 4.2 | The lowest height of the gantry after the drop | H1 (mm) | 2067 |
| 4.4. | Standard maximum lifting height | h3 (mm) | 2930 |
| 4.15 | The height of the fork after it drops | h13(mm) | 90 |
| 4.19 | The length of the vehicle | l1 (mm) | 1727 |
| 4.21 | Overall width | b1/ b2 (mm) | 834 |
| 4.25 | Forks with width | b5 (mm) | 570 |
| 4.34.1 | Right angle stacking channel width (pallet is 1000 length × 1200 width) | Ast (mm) | 2286 |
| 4.34.2 | Right angle stacking channel width (pallet is 800 width x 1200 length) | Ast (mm) | 2219 |
| 4.35 | Turning radius | Wa (mm) | 1455 |
| 5.1 | Walking speed, full load/no load | km/ h | 4.0/4.5 |
| 5.2 | Lift speed, full load/no load | m/ s | 0.085/0.13 |
| 6.4 | Battery voltage/nominal capacity | V/ ah | 24/80 |
