Based on domestic globalization, with a broad vision
Ultra high strength design, large tonnage and high lifting capacity;
Standard pedal arm guard and electric steering, easy and safe operation;
Drive bias, more stable;
Ultra high strength design, large tonnage and high lifting capacity;
Standard pedal arm guard and electric steering, easy and safe operation;
Drive bias, more stable;
| 1.1 | brand | Zhongli | |
| 1.2 | model | ES16-RS | |
| 1.3 | Power type | electric | |
| 1.4 | Operation Type | Station driving style | |
| 1.5 | Load Rated | Q (kg) | 1600 |
| 1.6 | Load center distance | c (mm) | 600 |
| 2.1 | Self-weight (including battery) | kg | 1240 |
| 4.2 | The lowest height of the gantry after the drop | H1 (mm) | 2020 |
| 4.4 | Standard gantry maximum lifting height | h3 (mm) | 2912 |
| 4.15 | The height of the fork after it drops | h13(mm) | 88 |
| 4.19 | The length of the vehicle | l1 (mm) | 2035 |
| 4.21 | Overall width | b1/ b2 (mm) | 850 |
| 4.25 | Forks with width | b5 (mm) | 570/685 |
| 4.34.1 | Right angle stacking channel width (pallet is 1000 length × 1200 width) | Ast (mm) | 2605/2965 |
| 4.34.2 | Right angle stacking channel width (pallet is 800 width x 1200 length) | Ast (mm) | 2575/2935 |
| 4.35 | Turning radius | Wa (mm) | 1730/2090 |
| 5.1 | Walking speed, full load/no load | km/ h | 5.5/6.0 |
| 5.2 | Lift speed, full load/no load | m/ s | 0.13/0.16 |
| 6.4 | Battery voltage/nominal capacity | V/ ah | 24V/210Ah |
