1.2 ton low-speed version low position picking truck
High performance, high reliability;
More secure;
Easy to operate;
Maintenance;
1.2 ton low-speed version low position picking truck
High performance, high reliability;
More secure;
Easy to operate;
Maintenance;
| 1.1 | brand | Zhongli | |
| 1.2 | model | EPL121P | |
| 1.3 | Power type | electric | |
| 1.4 | Operation Type | Station driving style | |
| 1.5 | Load Rated | Q (kg) | 1200 |
| 1.6 | Load center distance | c (mm) | 600 |
| 2.1 | Self-weight (including battery) | kg | 250 |
| 3.2 | Front wheel size (diameter × width) | F210x70 |
| 4.4. | Standard maximum lifting height | h3 (mm) | 105 |
| 4.15 | The height of the fork after it drops | h13(mm) | 85 |
| 4.19 | The length of the whole vehicle | l1 (mm) | 1950 |
| 4.20. | Length of the vertical plane of the arrival fork | l2 (mm) | 810 |
| 4.21 | Overall width | b1/ b2 (mm) | 726 |
| 4.22 | Fork size | s/ e/ l (mm) | 55/150/1150 |
| 4.25 | Forks with width | b5 (mm) | 685/560 |
| 4.34.1 | Right angle stacking channel width (pallet is 1000 length × 1200 width) | Ast (mm) | 2520 |
| 4.34.2 | Right angle stacking channel width (pallet is 800 width x 1200 length) | Ast (mm) | 2430 |
| 4.35 | Turning radius | Wa (mm) | 1760 |
| 5.1 | Walking speed, full load/no load | km/ h | 6/6.5 |
| 5.2 | Lift speed, full load/no load | m/ s | 0.026/0.031 |
| 5.3 | Descent speed, full load/no load | m/ s | 0.070/0.042 |
| 5.8 | Maximum climbing, full/unloaded | % | 8/16 |
| 6.4 | Battery voltage/nominal capacity | V/ ah | 48/20 |
