Technical Parameter
feature
| 1.1 |
brand |
|
Zhongli |
| 1.2 |
model |
|
TPL251 |
| 1.3 |
Power type |
|
electric |
| 1.4 |
Operation Type |
|
Picking |
| 1.5 |
Load Rated |
Q (kg) |
2500 |
| 1.6 |
Load center distance |
c (mm) |
600 |
weight
| 2.1 |
Self-weight (including battery) |
kg |
821 |
Tires, chassis
| 3.2 |
Front wheel size (diameter × width) |
|
F85x70 |
size
| 4.4. |
Standard maximum lifting height |
h3 (mm) |
120 |
| 4.15 |
The height of the fork after it drops |
h13(mm) |
85 |
| 4.19 |
The length of the vehicle |
l1 (mm) |
2526 |
| 4.20. |
Length of the vertical plane of the arrival fork |
l2 (mm) |
1375 |
| 4.21 |
Overall width |
b1/ b2 (mm) |
800 |
| 4.22 |
Fork size |
s/ e/ l (mm) |
55/190/1150 |
| 4.25 |
Forks with width |
b5 (mm) |
560/685 |
| 4.34.1 |
Right angle stacking channel width (pallet is 1000 length × 1200 width) |
Ast (mm) |
3006 |
| 4.34.2 |
Right angle stacking channel width (pallet is 800 width x 1200 length) |
Ast (mm) |
2941 |
| 4.35 |
Turning radius |
Wa (mm) |
2172 |
Performance parameters
| 5.1 |
Walking speed, full load/no load |
km/ h |
9.5/14.5 |
| 5.2 |
Lift speed, full load/no load |
m/ s |
0.032 / 0.044 |
| 5.3 |
Descent speed, full load/no load |
m/ s |
0.045 / 0.037 |
| 5.8 |
Maximum climbing, full/unloaded |
% |
5/16 |
Electric motor, power unit
| 6.4 |
Battery voltage/nominal capacity |
V/ ah |
24/280 |
